Pentax Papilio II Binoculars
Product options:
- Aspherical Lens Elements
- BAK4 Porro Prisms
- Fully Multicoated Optics
- Angle of View: 7.5° (6.5x21)
- Angle of View: 6° (8.5x21)
- Minimum Focus of 20"
- Center Focusing
- Twist-Up Eyecups
- 1/4"-20 Tripod Socket
The binocular is very compact, lightweight, and features a single piece frame that houses objectives, which allows for a synchronized interpupillary adjustment. To accommodate eye glasses wearers, the binocular offers twist-up rubber eyecups. Also included are a carrying case, a neck strap, and eyepiece covers.
Optical Performance
- BAK4 Porro prisms
- Aspherical optical elements offer edge-to-edge image sharpness
- Fully multicoated optics
- Minimum focus of 20"
- Interpupillary adjustment
- Diopter adjustment
Construction Details
- Single piece objectives' frame allows for a synchronized interpupillary adjustment
- Contoured body provides a comfortable grip
- Center focus knob offers an easy focusing
- Twist-up rubber eyecups
- Integrated 1/4"-20 tripod socket
|
Prism Type |
Porro |
|
Magnification |
6.5x / 8.5x |
|
Objective Lens Diameter |
21 mm |
|
Angle of View |
7.5° (actual) / 6° (actual) |
|
Field of View |
393.7' @ 1000 yd / 131.2 m @ 1000 m (6.5x21) |
|
Minimum Focus Distance |
10.4' / 3.2 m |
|
Exit Pupil Diameter |
3.2 mm (6.5x21), 2.5 mm (8.5x21) |
|
Eye Relief |
15 mm |
|
Interpupillary Adjustment |
Not Specified by Manufacturer |
|
Dioptric Correction |
Not Specified by Manufacturer |
|
Focus Type |
Center |
|
Tripod Mount |
Yes |
|
Dimensions |
4.5 x 4.4 x 2.1" / 11.4 x 11.2 x 5.3 cm (6.5x21) |
|
Weight |
10.2 oz / 289.2 g |
| Brochures | |
|---|---|
| 00ZPNTXPPLIIBNC - Brochure |
- Pentax 6.5x / 8.5x 21 U-Series Papilio II Binocular
- Eyepiece Covers
- Neck Strap
- Carrying Case
Brand: Pentax |
Code:
62001
Product options:
Brand: Pentax |
Code:
62001
