Vixen Ascot 8x32 ZWCF Binoculars
Waterproof design
Since it is a full-scale waterproof design, it can be used with confidence even in a sudden rain.※The photograph is an image.
High eye point design
The eye relief is 17mm and the high eye point design makes it easy to look into and it provides enough visibility to the surroundings even for those who wear glasses.
Excellent body exterior
Polymer elastomer material is used for the exterior. It fits comfortably in the hand and has excellent shock resistance.
Twist-up view with click mechanism
Uses a twist-up look with a click mechanism. It is very convenient because it can be expanded and contracted with one touch.
Porro prism
By adopting a Porro prism with excellent cost performance, you can get a clear view while ensuring a high degree of design freedom.
PFM coat
Uses PFM coat (Perfect Fully Multi Coat). Multi-coating is applied to the entire surface of the prism and lens (objective and eyepiece), resulting in extremely excellent contrast.
Can be mounted on a tripod
Binoculars can be fixed to a tripod by using Vino Holder H (sold separately) or Vino Holder MH (sold separately). We realize stable observation.
5 year warranty
If the product is used correctly according to the instruction manual and a malfunction occurs within 5 years from the date of purchase, we will repair the product free of charge.
| magnification | 8 times |
| Objective lens effective diameter | 32 mm |
| Prism material | BaK4 |
| Coating | PFM coat |
| Real field of view | 8.2 degrees |
| Apparent field of view | 65.6 degrees |
| 1000m vision | 143m |
| Pupil diameter | 4.0 mm |
| Brightness | 16 |
| Eye relief | 15.0 mm |
| Close range | About 4.5m |
| Pupil distance | About 59-72mm |
| Size/height x width x thickness | 11.3 x 17.7 x 5.8 cm |
| weight | 830g |
| Tripod mounting | Possible (using Vino Holder H or Vino Holder MH) |
| Other | Waterproof, wide angle |
Brand: Vixen |
Code: VX1560
APN: 4955295156009 |
Supplier Code: 1560
Brand: Vixen |
Code: VX1560
APN: 4955295156009 |
Supplier Code: 1560
At a glance
Binoculars designed for outdoor use with the highest priority. Wide-angle binoculars that make it easy to focus on nearby objects (close-up distance about 4.5m). It is easy to use and works well in many scenes.
