Pentax SMC XW 20mm Eyepiece for Spotting Scope
The XW 20 eyepiece is designed for use with a wide range of PENTAX spotting scopes and telescopes. Ideal for both ground and astronomical observations, this eyepiece features fully multi-coated lenses to increase light transmission and color quality, high-refraction lanthanum glass elements for high-resolution images with minimal aberrations, and JIS Class 4 weatherproof construction for durability. Engineered using advanced computer simulation design technology, this high-performance eyepiece provides a 70 degree field of view and 20mm eye relief.
This Eyepiece is Compatible with the PF-65 and PF-65 ED II series spotting scopes, PF-80 series spotting scopes, PF-100 series spotting scopes.
- Improved 70 degree field of view for wider views
- XW 3.5mm, 5mm, 7mm, 10mm, 14mm, 20mm, 30mm, and 40mm provide a wider field of view than previous PENTAX eyepieces
- All Pentax XW series eyepieces may be used with astronomical telescopes with appropriate 1 ?? or 2? focusers
- XW 3.5mm, 5mm, 7mm, 10mm, 14mm, 20mm eyepieces may be used with our PF series Spotting Scopes (except PF 63 Zoom)
- Full multi-coated lenses increase light transmission and contrast
- High refraction, extra-low dispersion lanthanum glass elements deliver bright, high resolution images with minimal distortions and aberrations
- Advanced computer simulation design technology implemented to drastically reduce internal reflections, producing brighter, clearer images
- Weatherproof construction for greater durability
- Long eye relief for comfortable viewing with or without glasses
LENS STRUCTURE |
6 elements, 4 groups |
FOCAL LENGTH |
20mm |
APPARENT FIELD OF VIEW |
70 degrees |
EYE RELIEF |
20mm |
ATTACHMENT DIAMETER |
1.25 (31.7mm) |
FILTER DIAMETER |
28.6mm |
FIELD STOP DIAMETER |
24.0mm |
EYEPIECE RING |
Helicoid type |
DIMENSIONS |
3.4 x 2.4 in |
WEIGHT |
12.6 oz. (355g) |
LENS STRUCTURE |
6 elements, 4 groups |
Brand: Pentax |
Code: 70516
APN: 0027075075245 |
Supplier Code: 70516
Brand: Pentax |
Code: 70516
APN: 0027075075245 |
Supplier Code: 70516
At a glance
