Pixfra Chiron C435 Thermal Scope OLED 35mm 12 um pix 384x288 dis 1440x1080 **
- Vanadium oxide uncooled focal plane detector.
- Ultra-low power consumption.
- Connects to the mobile app through Wi-Fi.
- Calculates distance using video analysis.
- Lightweight and portable.
- Picture in picture.
- Impact resistance reaches up to 1,000 g/1 ms.
- RAR (Recoil Activated Recorder).
- 1440 × 1080 OLED screen.
- Metal housing.
- IP67 rated.
Thermal
Detector Type |
Vanadium oxide uncooled focal plane detector |
Effective Pixels |
384 (H) × 288 (V) |
Pixel Pitch |
12 μm |
Spectral Range |
8 μm–14 μm |
Sensitivity (NETD) |
≤30 mK@f/1.0, 25°C |
Focal Length |
35 mm |
Aperture |
F1.0 |
Field of View |
H: 7.8°; V: 5.9° |
Focus Control |
Fixed |
Close Focus Distance |
2 m (6.56 ft) |
Detection Distance |
1,800 m (5,905.51 ft) |
Magnification |
2.95 × |
Frame Rate |
50 Hz |
Display
Screen |
1440 × 1080, 0.41 inch, OLED |
Color Palettes |
6 (white hot/black hot/iron red/alarm/emerald/amber) |
Video Compression |
H.264 |
Diopter Adjust |
–5 D to +5 D |
Eye Relief |
44 mm (1.73") |
Exit Pupil |
6 mm |
Function
Digital Zoom |
1×; 2×; 4×; 8× |
Reticle |
Multiple Patterns & Color Options |
Zeroing |
Yes |
Video Recorder |
Yes |
Snapshot |
Yes |
WiFi Hotspot |
Yes |
Hot Spot Track |
Yes |
Video Distance Measurement |
Yes |
FFC Calibration |
Auto; manual; immediately |
Standby Mode |
Yes |
PIP (Picture in Picture) |
Yes |
DPC (Defective Pixel Correction) |
Yes |
RAR (Recoil Activated Recorder) |
Yes |
Datasheets | |
---|---|
Pixfra Chiron C435 Thermal Scope OLED 35mm 12 um pix 384x288 dis 1440x1080 ** - Datasheet | Product Manuals |
Pixfra Chiron C435 Thermal Scope OLED 35mm 12 um pix 384x288 dis 1440x1080 ** - Product Manual |
Brand: Pixfra |
Code: PFI-C435
Supplier Code: 1.0.01.34.13860-0005
Brand: Pixfra |
Code: PFI-C435
Supplier Code: 1.0.01.34.13860-0005
At a glance
- Vanadium oxide uncooled focal plane detector.
- Ultra-low power consumption.
- Connects to the mobile app through Wi-Fi.
- Calculates distance using video analysis.
- Lightweight and portable.
- Picture in picture.
- Impact resistance reaches up to 1,000 g/1 ms.
- RAR (Recoil Activated Recorder).
- 1440 × 1080 OLED screen.
- Metal housing.
- IP67 rated.
